The Waveshare 0.85inch LCD Display Module is a compact, versatile, and vibrant display solution designed for a wide range of embedded electronics projects. Featuring a 0.85-inch IPS panel with a resolution of 128×128 pixels and support for 65K RGB colors, this module offers clear, colorful, and sharp visuals in a tiny footprint. Its SPI interface minimizes required IO pins, making it compatible with popular microcontroller boards like Raspberry Pi, Arduino, STM32, ESP32, RP2040, and Jetson series. This article explores the many possibilities and practical applications of the Waveshare 0.85inch LCD Display Module, including hardware integration, project ideas, programming tips, and development resources.
The Waveshare 0.85inch LCD Display Module is a small yet powerful display designed to fit into compact embedded systems where space is limited but display quality cannot be compromised. Its IPS panel technology ensures wide viewing angles and vivid color reproduction, making it ideal for displaying text, graphics, and animations with clarity. The 128×128 pixel resolution, while modest, is sufficient for many user interface elements and simple graphical outputs.
Designed with embedded developers in mind, this module integrates an embedded GC9107 driver and communicates via a 4-wire SPI interface. The SPI bus reduces the number of IO pins needed, which is a significant advantage for microcontroller projects with limited pin availability. The module comes with development resources and example codes for multiple platforms, accelerating the prototyping process.
| Feature | Description |
|---|---|
| Display Size | 0.85 inches diagonal |
| Resolution | 128 × 128 pixels |
| Display Panel | IPS (In-Plane Switching) |
| Color Depth | 65K RGB colors |
| Interface | 4-wire SPI |
| Driver IC | GC9107 |
| Operating Voltage | 3.3V |
| Dimensions | 19.0 × 22.5 mm |
| Pixel Pitch | 39.6 × 118.8 µm |
| Compatible Controllers | Raspberry Pi, Arduino, STM32, ESP32, RP2040, Jetson series |
The IPS panel technology ensures consistent color and brightness even at wide viewing angles. The embedded GC9107 driver supports RGB565 color format, which is standard for many embedded displays, providing smooth and vibrant color output. The SPI interface enables fast and efficient communication with microcontrollers while saving GPIO pins.
The Waveshare 0.85inch LCD Display Module is designed to work seamlessly with a variety of controller boards:
- Raspberry Pi (all models including Raspberry Pi Zero)
- Arduino (Uno, Mega, Nano, etc.)
- STM32 microcontrollers
- ESP32 and ESP32-S3
- RP2040 based boards (like Raspberry Pi Pico)
- NVIDIA Jetson Series
The module uses a 4-wire SPI interface, which includes pins for clock (SCL), data (SDA), chip select (CSX), and data/command control (D/CX). The reset pin (RESX) is used to initialize the display on power-up. This interface is widely supported and easy to implement on almost any microcontroller or single-board computer.
The module can be connected to the Raspberry Pi SPI pins:
- SCL to SPI Clock (GPIO11)
- SDA to SPI MOSI (GPIO10)
- CSX to SPI Chip Select (GPIO8)
- D/CX to any GPIO for Data/Command control
- RESX to any GPIO for Reset control
- Power the module with 3.3V and connect ground accordingly.
This setup allows the Raspberry Pi to control the display using SPI commands and libraries provided by Waveshare or third-party developers.
Arduino boards can interface with the module similarly:
- Use hardware SPI pins (e.g., MOSI, SCK, SS)
- Assign digital pins for D/CX and RESX
- Power the module at 3.3V (use level shifters if using 5V Arduino boards)
Example libraries and sample code are available to simplify initialization and drawing operations.
STM32 and ESP32 microcontrollers also support SPI communication natively. The module can be connected to SPI pins on these boards, and developers can use example code provided by Waveshare or community libraries to display graphics, text, and animations.
The compact size and colorful display of the Waveshare 0.85inch LCD Display Module make it suitable for numerous creative and practical applications:
Its small footprint and vibrant display are perfect for smartwatches, fitness trackers, or other wearable gadgets that require a clear user interface in a tiny package. The low power consumption and compact size help extend battery life while maintaining user-friendly visuals.
The 128×128 resolution is suitable for retro-style games or simple graphical interfaces in handheld gaming devices. Developers can create pixel art games, puzzles, or interactive menus that benefit from the module's vivid colors and fast refresh rate.
Connect the module to microcontrollers with sensors (temperature, humidity, pressure) to create compact data dashboards that show real-time readings. This is ideal for environmental monitoring, weather stations, or health monitoring devices.
Use it as a status display for IoT devices, showing network status, sensor data, or alerts in home automation projects. Its small size allows it to fit into smart appliances, security systems, or remote controls, providing intuitive feedback to users.
Develop small control panels or menus for embedded systems, robotics, or consumer electronics where space is limited. The Waveshare 0.85inch LCD Display Module can display icons, text, and graphics to enhance user interaction.
Ideal for teaching SPI communication, graphics programming, and embedded system design in schools and maker spaces. Students can learn how to interface displays, draw graphics, and manage data visualization on a compact screen.
Create stylish digital clocks, countdown timers, or stopwatches that fit in small enclosures. The clear display and bright colors make it easy to read time or countdown information at a glance.
Use the module as a notification panel for messages, alerts, or status updates in various devices. For example, it can show incoming calls, emails, or system warnings in compact electronics.
- Use the provided development resources: Waveshare offers example codes for Raspberry Pi, Arduino, STM32, ESP32, RP2040, and Jetson series to help you get started quickly.
- Initialize the display correctly: Follow the initialization sequence for the GC9107 driver to ensure proper operation.
- Optimize SPI speed: Adjust SPI clock speed for the best balance between performance and stability.
- Use RGB565 color format: This is the native format supported by the module for accurate color representation.
- Manage power carefully: The module operates at 3.3V; avoid applying higher voltages to prevent damage.
- Leverage graphics libraries: Use libraries like Arduino_GFX or custom drivers to simplify drawing shapes, text, and images.
- Implement double buffering: For smoother animations, use double buffering techniques to reduce flicker.
- Calibrate color settings: Adjust contrast and brightness through software commands if needed to match your project's environment.
- Protect the display: Use a protective cover or enclosure to prevent physical damage, especially in wearable or portable applications.
The Waveshare 0.85inch LCD Display Module is a powerful yet compact display solution ideal for embedded projects requiring a small footprint without sacrificing visual quality. Its IPS panel delivers vibrant colors and wide viewing angles, while the 128×128 resolution is sufficient for many user interface and graphical applications. Thanks to its SPI interface and embedded GC9107 driver, it integrates easily with popular microcontrollers and single-board computers such as Raspberry Pi, Arduino, STM32, ESP32, RP2040, and Jetson series.
Whether you are building wearable devices, portable consoles, IoT dashboards, or educational projects, this module offers flexibility, ease of use, and reliable performance. The availability of development resources and example codes further accelerates project development, making the Waveshare 0.85inch LCD Display Module a valuable component in your electronics toolkit.
The module features a 128×128 pixel resolution and supports 65K RGB colors (RGB565 format), providing clear and vibrant visuals.
It is compatible with Raspberry Pi, Arduino, STM32, ESP32, RP2040, and Jetson series boards, thanks to its SPI interface and available example code.
The display uses a 4-wire SPI interface, which reduces IO pin usage and supports fast data transmission.
The module operates at 3.3V. Ensure that both the supply voltage and logic voltage are consistent at 3.3V to avoid malfunction or damage.
Yes, Waveshare provides example codes and libraries for Raspberry Pi, Arduino, STM32, ESP32, RP2040, and Jetson series to facilitate integration and development.
