Home » Products » Touch Panel » CTP » 4.5 Inch 720x1280 LCD Touch Screen

4.5 Inch 720x1280 LCD Touch Screen

Model: KTD-HDP45604BTTB-V0
Terms: EXW, FOB, CIF
Product Origin: China
Min Order: 1000
Shipping Port: Shenzhen
Lead Time: 3~5 weeks
Availability:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

Item

4.5” 720*1280 LCD Touch screen

Brand

  Kelai (OEM, OEM acceptable)

Item No.

  KTD-HDP45604BTTB-V0

Resolution

  720*1280 dpi

Active area

  105.87*57.6 mm

Brightness

  400nits

Interface type

  MIPI

Pins

  35

Driver IC

 HX8389-C010PD200-P

Touch panel

  (optional)

Warranty

  1 year

Certificates

  ISO14001, ISO9001, ISO13485

Compliant

  ROHS, CE

Color

  Black


4.5 inch 720x1280 LCD Touch screen

KTD-HDP45604BTTB-V0 is a color active matrix TFT LCD screen using amorphous silicon TFT (Thin Film Transistors) as an active switching devices. This screen has a 4.5 inch diagonally measured active area with resolutions (720 horizontal by 1280 vertical pixel array). Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe. The TFT LCD panel used for this screen is adapted for a low reflection and higher color type. For this 4.5” 720*1280 LCD Touch screen, the screen connector is high grade flex cable, which is stable. The outer frame is unti-rust material. Quality is top priority. Our TFT IPS LCD screens are widely used in the following industries:


1.For Medical Equipment

B-ultrasound, anesthesia machine, laryngoscopic surgical in ICU,automatic injection equipment, gas station equipment and etc


2.For Industrial Control Equipment

equipment control panel,elevator,test instrument, energy storage equipment, car electricity charger, ATM, vending machine and etc.


3.For Smart Home

thermostat, HVAC,water dispenser, smart audio, soap dispenser, smart 8-6 houses and etc.


4.For Handheld Devices

POS, PDA, test meter, alcohol tester, logic device, and etc


5.For Automobile Equipment

GPS, car radio, car black box, agricultural tractor, forklift, E-bike, electrical motor cycle and etc


Support Custom

Customized LCD size & resolution (1”~15.6” available)
Customized interface and pins definition (MIPI, IPS, LVDS, RGB, UART, HDMI, SPI, etc)
Customized FPC shape and material


Our company have passed the ISO 9001, ISO 14001, ISO13584 quality system certification and SGS, RoHS, CE certification, to ensure all of our products and services are in international standard.


细节图-白底-改变图层3可换颜色






Hot tags:4.5 inch 720x1280 LCD touch screen, panel lcd display, TFT Touch Screen, lcd panel 4.5 inch, lcd display screen panel for consoles, mobile phone lcds touch screen, lcd screen display panel, Lcd Screen Display Car Screen, lcd android display, lcd bar touch display, China, customized, bulk, cheap, factory, suppliers, manufacturer
