The QK100 keyboard features an LCD display that enhances both its aesthetics and functionality[4]. This display can show various information, such as date, time, and custom GIFs[2][4]. Customizing this display allows users to personalize their keyboard, making it unique[4].
Before customizing the LCD, ensure your QK100 is properly set up.
1. Wired Mode: Connect your QK100 to your computer using a USB cable. The QK Config software may show a "no device found" error if the keyboard is not in wired mode[1].
2. Software Detection: Once in wired mode, the QK Config software should detect your keyboard[1].
3. QK Config: This software allows you to modify various keyboard settings, including keymaps and the LCD display[1].
The QK Config software interface is user-friendly, with different options on the left panel[1].
1. Keymaps: Customize key functions and create macros[1].
2. Lighting: Adjust the RGB lighting effects if your QK100 model supports it[1]. Note that some models, like the QK75, might have different lighting functions[1].
3. LCD Settings: Access the settings to manage and change the LCD display[1].
To change the LCD display content, follow these steps within the QK Config software:
1. Access LCD Settings: Navigate to the LCD settings section in the QK Config software[1].
2. Upload Images or GIFs: You can upload custom images or GIFs to be displayed on the LCD screen[2][4]. Ensure the files are compatible with the display's resolution[4].
3. Adjust Display Settings: Configure settings such as brightness, display duration, and transition effects[1].
Sometimes, you may encounter issues with the LCD display[2]. Here are some troubleshooting steps:
1. Firmware Update: Ensure your keyboard's firmware is up to date. Visit the Qwertykeys firmware page to download the latest version[2][10].
2. Reset the LCD: If the display malfunctions after loading a GIF, try resetting it. Unplugging and replugging the keyboard might help[2].
3. Flashing the Board: As a last resort, you may need to flash the board using QMK Toolbox[2][10].
- Check for Defects: Before fully assembling your keyboard, test the PCB for any defects using tweezers to connect the holes on each switch[1].
- Bent Pins: After inserting switches, check for bent pins that might prevent registration[1].
- Battery Life: Be mindful of battery usage if your QK100 is a tri-mode version. The LCD works wirelessly, but prolonged use may affect battery life[4].
- Community Support: Join the QK discord server for responsive support and troubleshooting advice[2].
For those who want to delve deeper into customization, consider these options:
Customize each layer to suit specific tasks[1].
1. Layer Configuration: Use the QK Config software to set different functions for each layer[1].
2. Media Buttons: Assign media controls to specific keys for quick access to volume and playback functions[1].
3. Knob Customization: If your QK100 has a knob, customize its functions for volume control, scrolling, or other shortcuts[1].
If your QK100 supports RGB lighting, customize the lighting effects to match your setup[1].
1. Software Control: Use the QK Config software to adjust colors, patterns, and brightness[1].
2. Preset Modes: Explore preset lighting modes for dynamic effects[1].
Here's a detailed, step-by-step guide to help you change the LCD display on your QK100 keyboard:
- QK100 Keyboard
- USB Cable
- Computer (Windows or macOS)
- QK Config Software
- Desired Images or GIFs
1. Visit Qwertykeys Website: Go to the official Qwertykeys website and navigate to the downloads section.
2. Download QK Config: Find the QK Config software for your specific QK100 model and operating system.
3. Install Software: Run the installer and follow the on-screen instructions to install the QK Config software.
1. Wired Mode: Ensure your QK100 is set to wired mode.
2. Connect USB Cable: Plug the USB cable into your QK100 and your computer.
3. Software Detection: Open the QK Config software. The software should automatically detect your keyboard. If it doesn't, ensure the keyboard is properly connected and in wired mode.
1. Navigate Menu: In the QK Config software, look for the "LCD Settings" or a similar option in the left-hand menu.
2. Open LCD Settings: Click on the LCD Settings option to open the LCD customization panel.
1. Select Upload Option: In the LCD settings panel, find the option to upload a new image or GIF.
2. Choose File: Click the "Browse" or "Choose File" button and select the image or GIF you want to display on the LCD screen.
3. File Compatibility: Ensure the file format and resolution are compatible with the QK100's LCD screen. Common formats include GIF, JPG, and PNG. The ideal resolution will depend on your specific QK100 model, so refer to the product manual for the exact specifications.
4. Upload File: Click the "Upload" or "Apply" button to upload the file to the keyboard.
1. Brightness: Adjust the brightness of the LCD screen to your preference.
2. Display Duration: Set how long the image or GIF should be displayed before looping or transitioning to the next image.
3. Transition Effects: Choose from various transition effects, such as fade, slide, or wipe, to make the display more visually appealing.
4. Preview: Use the preview option to see how the image or GIF looks on the LCD screen before finalizing the settings.
5. Apply Changes: Once you are satisfied with the settings, click the "Apply" or "Save" button to save the changes to the keyboard.
1. Check LCD Screen: Look at the LCD screen on your QK100 keyboard to ensure the new image or GIF is displayed correctly.
2. Adjust if Necessary: If the image is not displaying correctly, go back to the QK Config software and adjust the settings until it looks perfect.
- Qwertykeys Website: Official website for software, firmware, and support.
- Reddit: Subreddits like r/MechanicalKeyboards for community support and troubleshooting.
- Discord: QK Discord server for real-time help and advice.
Customizing the QK100 LCD display is a straightforward process that can significantly enhance your keyboard's aesthetics and functionality. By following the steps outlined in this guide, you can easily upload custom images and GIFs, adjust display settings, and troubleshoot common issues. Remember to keep your firmware updated and seek community support when needed.
- Visit the Qwertykeys website, download the latest firmware for your model, and follow the instructions to flash it using QMK Toolbox[10].
- Commonly supported formats include GIF, JPG, and PNG. Check your QK100 product manual for specific resolution and format requirements.
- Ensure your keyboard is in wired mode, properly connected to your computer, and that you have installed the correct drivers. Restarting the software or your computer might also help.
- Try unplugging and replugging the keyboard. If that doesn't work, you may need to re-flash the firmware.
- Yes, the LCD display works in wireless mode, but keep in mind that it may affect battery life[4].
